Запчасти Komatsu PC650-3 & PC650LC-3 СИСТЕМА СМАЗКИ МАСЛООХЛАДИТЕЛЬ СИСТЕМА СМАЗКИ МАСЛ. СИСТЕМА

1

1239 239 H1

TUBE, WATER BYPASS

2

1240 052 H1

O-RING

3

1239 201 H1

CONNECTION, WATER BYPASS

4

140 483 H1

BOLT, W/WASHER - 3/8-16 X 1 1/4

5

1239 332 H1

BOLT, W/WASHER - 5/16-18 X 3/4

6

1241 354 H1

HOSE, PLAIN

7

1241 351 H1

CLAMP, HOSE

8

1241 360 H1

GASKET, CONNECTION

9

1239 913 H1

CLIP

|$9

1241 365 H91

COOLER, ENGINE OIL

10

1237 989 H1

BOLT - 3/8-24 X 3 3/4

11

120 382

WASHER, LOCK

12

1238 127 H1

DRAINCOCK

13

1238 237 H1

WASHER, PLAIN

14

1238 775 H1

GASKET, OIL COOLER

15

1239 273 H1

BOLT, W/WASHER - 3/8-16 X 3 1/2

16

1241 342 H1

BOLT, W/WASHER - 3/8-16 X 1 5/8

17

1239 248 H2

GASKET, TORQUE CONVERTER OIL COOLER

18

1238 328 H1

O-RING

19

1241 313 H1

PLUG, THREADED

20

1241 364 H1

COVER, LUBE OIL COOLER

21

1239 931 H1

CORE, LUBE OIL COOLER

22

1239 934 H91

PLUG, THREADED

N/I

1241 503 H1

O-RING

23

1250 824 H1

HOUSING, OIL COOLER

24

120 382

WASHER, LOCK

25

1238 237 H1

WASHER, PLAIN

26

1241 309 H1

BOLT, TWELVE POINT - 3/8-16 X 1 3/4

27

1241 336 H1

BOLT, W/WASHER - 3/8-16 X 1 5/8

28

1239 759 H1

BOLT, W/WASHER - 3/8-16 X 1 1/4

|$28

120 382

WASHER, LOCK

30

1239 776 H1

BOLT, W/WASHER - 3/8-16 X 4

31

1239 878 H2

GASKET, LUBE OIL COOLER HOUSING
