Запчасти Komatsu PC650-3 & PC650LC-3 ЦИЛИНДР КОВША РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

|$0

209-63-02042

CYLINDER ASSEMBLY, BUCKET

1

209-63-72540

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-28-18510

HEAD, CYLINDER

5

707-51-13130

PACKING, ROD

6

707-51-13630

RING, BUFFER

7

707-52-91050

BUSHING

8

707-56-13520

SEAL, DUST

9

07179-14146

RING

10

07000-14171

O-RING

11

707-35-91850

RING, BACKUP

12

07001-05175

RING, BACKUP

13

707-7131360

COLLAR

14

707-71-11350

RING

15

01010-52485

BOLT

16

209-63-72520

ROD, PISTON

17

707-46-11520

BUSHING

18

707-71-51361

PLUNGER

|$19

707-91-01812

PISTON ASSEMBLY

19

707-37-18011

PISTON

20

NSS

SEAT

21

NSS

VALVE, PISTON

22

NSS

SPRING

23

NSS

VALVE

24

707-71-91410

SPACER

25

01252-31485

BOLT

26

07000-12110

O-RING

27

707-35-52950

RING, BACKUP

28

707-39-18820

RING, WEAR

29

707-44-18180

RING, PISTON

30

707-40-18970

SPACER

31

707-37-18020

PISTON

32

07283-23442

CLIP

33

01599-01011

NUT

34

01643-31032

WASHER

35

209-63-72570

TUBE

36

209-62-58410

TUBE

37

07000-13038

O-RING

38

01010-51245

BOLT

39

01643-31232

WASHER

40

707-88-96061

BAND

41

07378-11210

HEAD, SLEEVE

42

07371-51260

FLANGE, SPLIT

43

01010-51240

BOLT

44

01643-31232

WASHER

45

707-88-96050

BAND

46

209-62-58560

BRACKET
