Запчасти Komatsu PC650-3 & PC650LC-3 ЦИЛИНДР РУКОЯТИ РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

|$0

209-63-02031

CYLINDER ASSEMBLY, ARM

1

209-63-62540

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-28-20520

HEAD, CYLINDER

5

707-51-14130

PACKING, ROD

6

707-51-14630

RING, BUFFER

7

707-52-91150

BUSHING

8

198-63-93170

SEAL, DUST

9

07179-14160

RING, SNAP

10

07000-15195

O-RING

11

707-35-92050

RING, BACKUP

12

01252-31490

BOLT

13

07001-05195

RING, BACKUP

14

707-71-31460

COLLAR

15

707-71-11450

RING

16

01010-52790

BOLT

17

209-63-62520

ROD, PISTON

18

707-46-11520

BUSHING

19

07043-00108

PLUG

|$20

707-91-02081

PISTON ASSEMBLY

20

NSS

PISTON

21

NSS

SEAT, VALVE

22

NSS

VALVE

23

NSS

SPRING

24

NSS

VALVE, PISTON

25

07000-12115

O-RING

26

707-35-52860

RING, BACKUP

27

707-39-20820

RING, WEAR

28

707-44-20180

RING, PISTON

29

707-40-20970

SPACER

30

707-71-50390

PLUNGER

31

04260-01270

BALL

32

707-71-91360

PIN

33

707-37-20020

PISTON

34

707-71-51461

PLUNGER

35

01010-51455

BOLT

36

01643-31445

WASHER

37

209-63-62570

TUBE

38

07000-13038

O-RING

39

01010-51280

BOLT

40

01643-31232

WASHER

41

707-88-96110

BAND

42

707-88-96130

BAND

43

01010-51240

BOLT

44

07283-24346

CLIP

45

01599-01011

NUT

46

01643-31032

WASHER

47

07378-11410

HEAD, SLEEVE

48

07371-51470

FLANGE, SPLIT
