Запчасти Komatsu PC650-3 & PC650LC-3 ЦИЛИНДР СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

|$0

209-63-02011

CYLINDER ASSEMBLY, BOOM

1

209-63-52540

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-28-20510

HEAD, CYLINDER

5

707-51-14130

PACKING, ROD

6

707-51-14630

RING, BUFFER

7

707-52-91150

BUSHING

8

198-63-93170

SEAL, DUST

9

07179-14160

RING, SNAP

10

07000-15195

O-RING

11

707-35-92050

RING, BACKUP

12

07000-15195

O-RING

13

07001-05195

RING, BACKUP

14

707-71-31460

COLLAR

15

707-71-11450

RING

16

01010-52790

BOLT

17

209-63-52520

ROD, PISTON

18

707-46-11520

BUSHING

19

07043-00108

PLUG

|$20

707-91-02062

PISTON ASSEMBLY

20

NSS

PISTON

21

NSS

SEAT, VALVE

22

NSS

VALVE

23

NSS

SPRING

24

NSS

VALVE, PISTON

25

07000-12115

O-RING

26

707-35-52860

RING, BACKUP

27

707-39-20820

RING, WEAR

28

707-44-20180

RING, PISTON

29

707-40-20970

SPACER

30

707-37-20020

PISTON

31

707-71-51461

PLUNGER

32

01252-31490

BOLT

33

07283-23442

CLIP

34

209-63-52570

TUBE - L.H

|$36

209-63-52670

TUBE - R.H

35

209-62-58180

TUBE - L.H

|$38

209-62-58190

TUBE - R.H

36

07000-13038

O-RING

37

01010-51245

BOLT

38

01643-31232

WASHER

39

07378-11210

HEAD, SLEEVE

40

07371-51260

FLANGE, SPLIT

41

01599-01011

NUT

42

01643-31032

WASHER

43

707-88-96110

BAND

44

707-88-96120

BAND

45

01010-51240

BOLT

46

01643-31232

WASHER
