Запчасти Komatsu PC650-3 & PC650LC-3 УПРАВЛЯЮЩ. КЛАПАН - ЛЕВ. УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$0

709-15-92100

VALVE ASSEMBLY, CONTROL - L.H

1

NSS

BODY

2

NSS

SPOOL, BOTTOM

3

NSS

SPOOL, BOOM

4

NSS

SPOOL, ARM

5

NSS

SPOOL, BUCKET

6

NSS

SPOOL, L.H. TRAVEL

7

709-14-11530

RETAINER

8

709-14-11620

TUBE

9

709-14-11540

TUBE

10

709-14-11560

SPRING, INNER

11

709-14-11550

SPRING, OUTER

12

709-14-11520

CASE

13

07000-02065

O-RING

14

01252-31035

BOLT

15

709-12-11411

VALVE, CHECK

16

709-12-11430

SPRING

17

709-12-12440

PLATE

18

07000-13048

O-RING

19

01010-51250

BOLT

20

01602-21236

WASHER, SPRING

21

709-10-91320

SLEEVE

22

706-73-70140

VALVE, CHECK

23

706-73-70150

SPRING

24

709-74-92450

PLUG

25

07000-12010

O-RING

26

07001-02010

RING, BACKUP

27

700-93-11320

O-RING

28

700-93-11330

RING, BACKUP

29

709-74-92460

NUT

30

709-14-11510

PLUG

31

700-80-61260

O-RING

32

700-80-61430

RING, BACKUP

33

700-22-11370

PLUG

34

07002-02434

O-RING

35

700-94-11260

PLUG

36

07000-12018

O-RING

37

07001-02018

RING, BACKUP

38

07002-03634

O-RING
