Запчасти Komatsu PC650-3 & PC650LC-3 ПОВОРОТН. ГИДР. НАСОС. CO & NC КЛАПАН УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$0

708-17-17100

VALVE ASSEMBLY, CO & NC

|$1

708-23-00310

BODY ASSEMBLY

1

NSS

BODY

2

NSS

PLUG

3

708-25-17140

SPOOL

4

708-25-17131

COVER

5

708-25-17180

SEAT

6

708-25-17190

SPRING

7

708-25-17122

PLUG

8

07000-02012

O-RING

9

07000-02021

O-RING

10

07001-02021

RING, BACKUP

11

708-25-15320

BOLT

12

01602-20619

WASHER, SPRING

13

01580-10806

NUT

14

708-25-17150

SLEEVE

15

708-25-17160

PISTON

16

708-25-17170

COVER

17

07000-02014

O-RING

18

708-25-15320

BOLT

19

01602-20619

WASHER, SPRING

20

708-25-17140

SPOOL

21

708-25-17210

SLEEVE

22

07000-02012

O-RING

23

07001-02012

RING, BACKUP

24

708-25-17220

PISTON

25

708-25-17230

COVER

26

07000-02012

O-RING

27

708-25-15320

BOLT

28

01602-20619

WASHER, SPRING

29

708-25-17370

SEAT

30

708-25-17250

SPRING

31

708-25-17260

SEAT

32

708-25-17290

PLUG

33

07000-11009

O-RING

34

708-25-17350

COVER

35

07000-03028

O-RING

36

708-25-15320

BOLT

37

01602-20619

WASHER, SPRING

38

01580-10806

NUT

39

07040-11007

PLUG

40

07002-01023

O-RING
