Запчасти Komatsu PC650-3 & PC650LC-3 ПОВОРОТН. ГИДР. НАСОС. END КРЫШКАS УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$0

708-17-21100

PUMP ASSEMBLY, SWING

|$1

708-27-00180

END CAP ASSEMBLY, FRONT

1

NSS

CAP

2

NSS

PLUG

3

708-27-12740

BEARING

4

708-27-12530

O-RING

5

07000-12015

O-RING

6

07000-12012

O-RING

7

708-18-13230

PIN

8

708-25-12330

JOINT

9

708-27-12550

BOLT

10

06000-51109

BEARING

11

708-27-22610

IMPELLER

12

04000-00515

KEY

13

708-18-12860

PLATE

14

708-27-00220

KIT, SHIM

|$16

NSS

SHIM - 0.1MM

|$17

NSS

SHIM - 0.2MM

|$18

NSS

SHIM - 0.5MM

15

708-27-14490

BOLT

|$20

708-27-00190

END CAP ASSEMBLY, REAR

16

NSS

CAP

17

NSS

PLUG

18

708-17-12540

O-RING

19

07000-12015

O-RING

20

07000-12012

O-RING

21

04020-01024

PIN, DOWEL

22

01141-82040

STUD

23

708-27-12570

NUT

24

01643-32060

WASHER

25

708-17-22540

COVER

26

708-27-12530

O-RING

27

07000-12015

O-RING

28

07000-12012

O-RING

29

01010-62055

BOLT

30

01643-32060

WASHER

31

07378-11210

HEAD, SLEEVE

32

07000-13038

O-RING

33

07371-41260

FLANGE

34

01010-51245

BOLT

35

01643-31232

WASHER

36

720-68-15240

FILTER

37

708-27-22530

FLANGE

38

07000-02021

O-RING

39

01010-31025

BOLT

40

01543-31032

WASHER
