Запчасти Komatsu PC650-3 & PC650LC-3 ГИДР. НАСОС. NO. END КРЫШКАS УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$0

708-25-51201

PUMP ASSEMBLY - NO. 2

|$1

708-25-00340

END CAP ASSEMBLY, FRONT

1

NSS

CAP

2

NSS

PLUG

3

NSS

END CAP, REAR

4

708-25-12740

BEARING

5

06000-51106

BEARING

6

708-25-05140

KIT, WASHER

|$8

NSS

WASHER - 2.25MM

|$9

NSS

WASHER - 2.55MM

|$10

NSS

WASHER - 2.85MM

|$11

NSS

WASHER - 3.15MM

|$12

NSS

WASHER - 3.45MM

|$13

NSS

WASHER - 3.75MM

7

708-25-52830

RING

8

708-25-52840

RETAINER

9

708-25-12950

PLATE

10

708-25-05020

KIT, SHIM

|$18

NSS

SHIM - 0.1MM

|$19

NSS

SHIM - 0.15MM

|$20

NSS

SHIM - 0.2MM

|$21

NSS

SHIM - 0.5MM

11

706-74-40320

BOLT

12

01643-31032

WASHER

13

708-25-52550

COUPLING

14

708-25-12542

IMPELLER

15

706-63-42270

SCREW

16

07000-02135

O-RING

17

07000-03032

O-RING

18

07000-12015

O-RING

19

07000-11009

O-RING

20

6130-21-1910

PIN

21

720-68-19160

PIN, DOWEL

22

708-25-12530

BOLT

23

07000-05165

O-RING

24

07000-03032

O-RING

25

07000-11009

O-RING

26

720-68-19610

PIN, DOWEL

27

01141-81620

STUD

28

01140-81645

STUD

29

01582-01613

NUT

30

01643-31645

WASHER
