Запчасти Komatsu PC650-3 & PC650LC-3 ГИДР. НАСОС. NO. ЗАДН. CO & NC КЛАПАН УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$0

708-25-57200

VALVE ASSEMBLY, REAR CO & NC

|$1

708-23-00310

BODY ASSEMBLY

1

NSS

BODY

2

NSS

PLUG

3

708-25-17141

SPOOL

4

708-25-17131

COVER

5

708-25-17180

SEAT

6

708-25-17190

SPRING

7

708-25-17420

PLUG

8

708-25-17430

SCREW

9

07000-02010

O-RING

10

07000-12021

O-RING

11

07001-02021

RING, BACKUP

12

708-25-15320

BOLT

13

01602-20619

WASHER, SPRING

14

01580-10806

NUT

15

708-25-17150

SLEEVE

16

708-25-17160

PISTON

17

708-25-17170

COVER

18

07000-02014

O-RING

19

708-25-15320

BOLT

20

01602-20619

WASHER, SPRING

21

708-25-17141

SPOOL

22

708-25-17211

SLEEVE

23

708-25-17220

PISTON

24

708-25-17230

COVER

25

07000-02012

O-RING

26

708-25-15320

BOLT

27

01602-20619

WASHER, SPRING

28

708-25-17370

SEAT

29

708-25-17250

SPRING

30

708-25-17260

SEAT

31

708-25-17410

PLUG

32

708-25-15340

SCREW

33

07000-01009

O-RING

34

708-25-17350

COVER

35

07000-03028

O-RING

36

708-25-15320

BOLT

37

01602-20619

WASHER, SPRING

38

01580-10806

NUT

39

07040-11007

PLUG

40

07002-01023

O-RING
