Запчасти Komatsu PC650-3 & PC650LC-3 ГИДР. БАК. С БЛОКИР. УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$0

209-60-00110

TANK ASSEMBLY, HYDRAULIC - WITH LOCK

1

NSS

TANK

2

203-60-31100

ELBOW ASSEMBLY

3

203-60-31160

TUBE

4

205-60-51480

SCREEN

5

205-60-51460

GASKET

6

201-60-12171

FILLER

7

01220-40516

SCREW

8

01601-20513

WASHER, SPRING

9

209-60-51180

CAP

10

07000-05230

O-RING

11

209-60-51161

COVER

13

209-60-51140

COVER

14

205-60-71220

LOCK ASSEMBLY

15

209-60-51150

BRACKET

16

01010-51240

BOLT

17

01643-31232

WASHER

18

12R-60-11230

SPRING

19

209-60-11131

SUPPORT

20

209-60-51120

STRAINER

21

21N-09-11140

O-RING

|$22

155-60-12500

VALVE ASSEMBLY

22

155-60-12510

BODY

23

04025-00532

PIN

24

155-60-12520

VALVE

25

07005-02416

GASKET

26

07040-12412

PLUG

27

07000-03025

O-RING

28

01010-51025

BOLT

29

01643-31032

WASHER

30

07000-02055

O-RING

31

600-815-3210

CASE

32

01010-51075

BOLT

33

01643-31032

WASHER

34

207-60-11350

TUBE

35

07280-01110

CLAMP

36

01010-52045

BOLT

37

01643-32060

WASHER
