Запчасти Komatsu PC600LC-8E0 ПОДАЮЩ. ТРУБЫ, НАСОС - ФИЛЬТР. (№-) ПОДАЮЩ. ТРУБЫ, ДЛЯ ПРОТИВОВЕС REMOVER

1

21M-62-11750

Hose

2

07000-B3025

O-ring

3

07371-30640

Flange, Split

4

07372-21035

Bolt

5

01643-51032

Washer

6

21M-62-31290

Bracket

7

21M-62-31250

Bracket

8

01010-81230

Bolt

9

01643-31232

Washer

10

07283-32244

Clip

11

07283-52232

Seat

12

01597-01009

Nut

13

01643-31032

Washer

14

21M-62-31310

Block

15

07000-B3032

O-ring

16

209-62-61310

Nipple Assembly

17

209-62-61330

O-ring

18

21M-62-11110

Block

19

07000-B3032

O-ring

19

21M-62-21890

Valve Assembly

20

207-60-31730

Pin

21

20Y-970-3350

Flange

22

Block

23

209-62-75221

Shaft

24

01010-81025

Bolt

25

01643-31032

Washer

26

01010-81040

Bolt

27

01643-31032

Washer

28

04025-00412

Pin, Spring

29

07000-B3042

O-ring

30

07000-B3048

O-ring

31

07000-B3032

O-ring

32

209-62-61310

Nipple Assembly

33

209-62-61330

O-ring

34

01011-81000

Bolt

35

01643-31032

Washer

36

02782-10315

Elbow

37

07002-62034

O-ring

38

02896-61009

O-ring

|$39

21M-60-11301

Filter Assembly

39

21M-60-11311

Case

40

Case

41

01010-81285

Bolt

42

01643-51232

Washer

43

07000-12055

O-ring

44

07000-13038

O-ring

45

07001-02055

Ring, Back-up

46

07002-11023

O-ring

47

07040-11007

Plug

48

07063-21200

Element

49

01010-81235

Bolt

50

01643-31232

Washer

51

21M-62-11621

Bracket

52

01010-81250

Bolt

53

175-54-34170

Washer

54

21M-62-21470

Bracket

55

01010-81680

Bolt

56

01643-31645

Washer
