Запчасти Komatsu PC600LC-8E0 ПРИВОД НАСОС, НАСОС ВЕНТИЛЯТОРА (/7) (№-) ПРИВОД НАСОС

Схема запчастей Komatsu PC600LC-8E0 - ПРИВОД НАСОС, НАСОС ВЕНТИЛЯТОРА (/7) (№-) ПРИВОД НАСОС
2
2
17
1
2
5
6
7
8
9
10
12
13
14
15
16
17
18
19
20
21
22
23
24
26
25
2
2
3
4
11

Артикул

Название

Примечание

Количество

|$0

708-1U-00202

Pump Assembly

|$1

708-1U-00213

Pump Assembly

|$2

708-1U-01218

Pump Subassembly

|$3

708-1U-04143

Case Assembly

1

Case

2

Plug

3

Sleeve

4

Ring

5

708-8E-16160

Plug

6

07002-11023

O-ring

7

07040-12412

Plug

8

07002-12434

O-ring

9

706-73-42370

O-ring

10

07000-B1009

O-ring

11

708-1L-29340

Orifice

12

04020-01024

Pin, Dowel

13

01010-61470

Bolt

14

01643-31445

Washer, Flat

15

708-1U-11562

Cap, End

16

708-1W-42120

Bearing

17

708-1U-13461

Ball, Retainer

18

708-1U-13450

Cam, Rocker

19

04260-01270

Ball

20

708-1U-12120

Shaft

21

708-1W-42110

Bearing

22

708-1W-42140

Case

23

708-1W-42130

Seal, Oil

24

07000-B2060

O-ring

25

708-1W-05821

Spacer Kit

|$29

Spacer, T=2.5mm

|$30

Spacer, T=2.55mm

|$31

Spacer, T=2.6mm

|$32

Spacer, T=2.65mm

|$33

Spacer, T=2.7mm

|$34

Spacer, T=2.75mm

|$35

Spacer, T=2.8mm

|$36

Spacer, T=2.85mm

|$37

Spacer, T=2.9mm

26

04065-06825

Ring, Snap

Выбрано товаров: 39
