Запчасти Komatsu PC600LC-8 МОТОР ВЕНТИЛЯТОРА (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-7W-00120

MOTOR ASSEMBLY

1

708-7W-11920

O-RING

2

04020-01024

PIN

3

01252-61480

BOLT

4

708-7W-12130

SHAFT

5

708-7W-12120

BEARING

6

708-7L-12140

BEARING

7

708-7L-05010

SPACER KIT

|7

SPACER, 1.5MM

|7

SPACER, 1.6MM

|7

SPACER, 1.7MM

|7

SPACER, 1.8MM

|7

SPACER, 1.9MM

|7

SPACER, 2.0MM

8

708-25-52861

SEAL, OIL

9

708-2L-22160

SPACER

10

04065-06825

RING

11

708-8F-33121

BLOCK, CYLINDER

12

708-8F-33230

PLATE, VALVE

13

720-68-19610

PIN

14

708-8F-33360

PIN

15

708-7L-13140

SEAT

16

708-8F-33160

SPRING

17

04065-04818

RING

18

708-8F-33350

GUIDE, RETAINER

19

708-2L-33350

RETAINER, SHOE

20

708-8F-33310

PISTON SUB ASSEMBLY

21

708-7L-13410

PLATE, THRUST
