Запчасти Komatsu PC600LC-8 МОТОР ПОВОРОТА (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-75-01461

MOTOR ASSEMBLY

|1

706-75-01460

MOTOR ASSEMBLY

|1

706-75-03451

MOTOR SUB ASSEMBLY

|1

706-75-03450

MOTOR SUB ASSEMBLY

1

706-75-43680

SHAFT, DRIVE

2

706-75-43880

BEARING

3

706-75-43810

SPACER

4

706-7E-11260

SPRING

5

706-7E-11270

SEAT

6

706-76-40890

BEARING

7

706-75-05040

SPACER KIT

|7

SPACER, 3.1MM

|7

SPACER, 3.4MM

|7

SPACER, 3.7MM

8

04064-04518

RING, SNAP

9

706-75-43410

SEAL

|9

706-7E-11280

SEAL

10

706-7G-41910

SPACER

|10

706-75-43720

SPACER

11

04065-06220

RING

12

706-75-43190

BLOCK, CYLINDER

13

706-75-43841

PLATE, VALVE

14

706-75-43750

PIN, DOWEL

15

706-75-43120

SHAFT, CENTER

16

706-75-43130

RING, CENTER

17

706-75-43140

SPRING

|18

706-75-05020

RETAINER KIT

18

RETAINER

19

SCREW

20

706-75-43160

PISTON SUB ASSEMBLY

21

706-75-92130

PLATE

22

706-75-92340

PLATE

23

706-75-92350

DISK

24

706-75-92380

PISTON, BRAKE

25

706-75-92390

RING, BRAKE

26

07000-B2145

O-RING

|26

07000-12145

O-RING

27

708-1W-49170

O-RING

|27

706-75-92310

O-RING

28

706-75-92360

SPRING
