Запчасти Komatsu PC600LC-8 МОТОР ПОВОРОТА (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-75-01461

MOTOR ASSEMBLY

|1

706-75-01460

MOTOR ASSEMBLY

|1

706-75-03451

MOTOR SUB ASSEMBLY

|1

706-75-03450

MOTOR SUB ASSEMBLY

1

706-75-43220

CASE

|2

706-75-00150

HOUSING SUB ASSEMBLY

2

HOUSING

3

PLUG

4

706-75-40010

BEARING

5

706-75-42820

PIN, DOWEL

6

706-77-72170

PLUG

7

07002-62434

O-RING

|7

07002-12434

O-RING

8

708-8H-11530

PLUG

9

07002-61423

O-RING

|9

07002-11423

O-RING

10

709-25-11650

VALVE, CHECK

11

709-25-11361

SPRING

12

709-25-11640

PLUG

13

07000-B2020

O-RING

|13

07000-12020

O-RING

14

706-75-74540

VALVE

15

706-75-74550

SPRING

16

706-75-74850

PLUG

17

07002-63334

O-RING

|17

07002-13334

O-RING

18

706-75-42450

O-RING

|18

565-14-22440

O-RING

19

01252-61445

BOLT
