Запчасти Komatsu PC600LC-8 BM ЦИЛИНДР, ЛЕВ. (С ПРЕДОТВРАЩЕНИЕМ СМЕЩЕНИЯ КЛАПАН) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XR960

CYLINDER GROUP, L.H. (FINAL COATING)

|1

707-01-0J630

BOOM CYLINDER ASSEMBLY

1

707-13-18950

CYLINDER

2

707-76-11160

BUSHING

3

07145-00110

SEAL, DUST (KIT)

4

07020-00000

FITTING, GREASE

5

07043-00108

PLUG

6

707-58-12660

ROD

7

707-76-12530

BUSHING

8

07145-00125

SEAL, DUST (KIT)

9

707-71-32900

COLLAR

10

707-35-91840

RING, BACK-UP (KIT)

11

07000-15175

O-RING (KIT)

12

707-71-61330

PLUNGER

13

707-27-18930

HEAD

14

195-63-93170

SEAL, DUST (KIT)

15

07179-13136

RING, SNAP

16

707-52-90980

BUSHING

17

07179-13126

RING, SNAP

18

707-51-12030

PACKING, ROD (KIT)

19

707-51-12650

RING, BUFFER (KIT)

20

707-35-91840

RING, BACK-UP (KIT)

21

07000-15175

O-RING (KIT)

22

01011-82400

BOLT

23

707-88-75410

WASHER

24

707-36-18520

PISTON

25

01310-01225

SCREW

26

707-44-18250

RING, PISTON (KIT)

27

707-39-18510

RING, WEAR (KIT)

28

707-44-18920

RING

29

07001-05110

RING, BACK-UP (KIT)

30

07000-15110

O-RING (KIT)

31

707-86-13240

TUBE, L.H.

32

07372-21060

BOLT

33

01643-51032

WASHER

34

07000-13035

O-RING (KIT)

35

707-88-28240

BRACKET

36

707-88-26120

BAND

37

07372-21240

BOLT

38

01643-51232

WASHER

39

07283-33442

CLIP

40

01643-31032

WASHER

41

01597-01009

NUT

42

707-88-33040

CAP

43

07371-31049

FLANGE, SPLIT

44

07372-21035

BOLT

45

01643-51032

WASHER

|K

707-99-76130

SERVICE KIT
