Запчасти Komatsu PC600LC-8 ОСНОВН. НАСОС (7/9) (NO. НАСОС) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|1
708-2L-90722
PUMP ASSEMBLY
|1
708-2L-90721
PUMP ASSEMBLY
|1
708-25-08191
SERVO VALVE ASSEMBLY, FRONT
|1
708-25-08190
SERVO VALVE ASSEMBLY, FRONT
|1
708-25-00840
BODY ASSEMBLY
|1
708-25-00421
BODY ASSEMBLY
1
BODY
2
EXPANDER
3
708-25-15120
PISTON
4
708-25-15130
SEAT
5
708-25-25130
SPRING
6
708-25-55250
SPRING
7
708-23-15120
SEAT
8
708-23-15160
PLUG
9
07000-B2018
O-RING
|9
07000-12018
O-RING
10
708-25-15150
COVER
11
01580-10806
NUT
12
01252-60616
BOLT
13
01602-20619
WASHER
14
708-25-15171
PLUG
15
07002-62034
O-RING
|15
07002-12034
O-RING
16
07239-12009
NUT
17
708-25-15180
SLEEVE
18
708-25-15280
SPOOL
19
708-25-15310
SPRING
20
708-25-15330
SPACER
21
708-25-15430
PLUG
22
708-25-15340
SCREW
23
07000-B2012
O-RING
|23
07000-12012
O-RING
24
708-25-15250
COVER
25
01252-60616
BOLT
26
01602-20619
WASHER
27
708-25-15260
PLUG
28
07002-60823
O-RING
|28
07002-10823
O-RING
29
708-25-15270
ARM
30
708-25-15360
PIN
31
708-25-15370
WASHER
32
708-25-15380
E-RING
33
07040-11007
PLUG
34
07002-61023
O-RING
|34
07002-11023
O-RING
35
708-25-55110
PLATE
36
07000-B2011
O-RING
|36
07000-12011
O-RING
37
01010-80825
BOLT
38
708-2L-25480
FILTER
|38
720-68-11920
FILTER
39
708-2L-25490
O-RING
|39
07000-12010
O-RING
40
07000-B1009
O-RING
|40
07000-11009
O-RING
41
708-25-19230
ORIFICE
|41
708-25-19150
ORIFICE
42
708-25-19250
PLUG
|42
708-25-19290
PLUG
43
01643-50823
WASHER
44
07000-B13048
O-RING
|44
07000-13048
O-RING
45
708-25-15460
SHIM, 0.05MM
|45
708-25-15470
SHIM, 0.10MM
46
708-2L-25490
O-RING
|46
07000-12010
O-RING
Выбрано товаров: 66
