Запчасти Komatsu PC600LC-8 ОСНОВН. НАСОС (/) (NO. НАСОС) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2L-00771

PUMP ASSEMBLY

|1

708-2L-00770

PUMP ASSEMBLY

|1

708-2L-01632

PUMP SUB ASSEMBLY

|1

708-2L-04960

CASE ASSEMBLY, REAR

1

CASE, REAR

2

PLUG

3

07044-12412

PLUG

4

07002-62434

O-RING

5

708-2L-21540

CAP, END

6

708-2L-32260

BEARING

7

07000-B2135

O-RING

8

6130-21-1910

PIN, DOWEL

9

07000-B2015

O-RING

10

07000-B1009

O-RING

11

07000-B5165

O-RING

12

07000-B3032

O-RING

13

708-25-12530

BOLT

14

04530-11018

BOLT, EYE

15

708-25-13630

RING

16

708-2L-22440

SHAFT, REAR

17

708-2L-32150

BEARING

18

708-2E-05040

WASHER KIT

|18

WASHER, 3.1MM

|18

WASHER, 3.0MM

|18

WASHER, 2.9MM

|18

WASHER, 2.8MM

19

708-25-12790

RING, SNAP

20

708-25-05021

SHIM KIT

|20

SHIM, 0.5MM

|20

SHIM, 0.2MM

|20

SHIM, 0.15MM

|20

SHIM, 0.1MM

21

708-25-12950

PLATE

22

706-74-40320

BOLT

23

01643-31032

WASHER

24

01252-31016

BOLT

25

708-25-05130

SHIM KIT

|25

SHIM, 0.2MM

|25

SHIM, 0.1MM
