Запчасти Komatsu PC600LC-8 ЦИЛИНДР КОВША ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XR640

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0J660

BUCKET CYLINDER A.

1

707-13-18960

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-13250

ROD

6

707-76-11130

BUSHING

7

07145-00110

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

07043-00108

PLUG

10

707-71-31760

COLLAR

11

707-27-18180

HEAD

12

707-56-13520

SEAL,DUST (KIT)

13

07179-14146

RING,SNAP

14

707-52-91070

BUSHING

15

07179-13136

RING

16

707-51-13030

PACKING,ROD (KIT)

17

707-51-13650

RING,BUFFER (KIT)

18

707-35-91840

RING,BACK-UP (KIT)

19

07000-15175

O-RING (KIT)

20

01011-82400

BOLT

21

707-88-75410

WASHER

22

707-71-61430

PLUNGER

23

707-36-18530

PISTON

24

01310-01225

SCREW

25

707-44-18250

RING,PISTON (KIT)

26

707-39-18510

RING,WEAR (KIT)

27

707-44-18920

RING

28

07001-05120

RING,BACK-UP (KIT)

29

07000-15120

O-RING (KIT)

30

707-86-13270

TUBE

31

21M-63-72181

TUBE

32

07372-21060

BOLT

33

01643-51032

WASHER

34

07000-13035

O-RING (KIT)

35

707-88-28260

BRACKET

36

707-88-26140

BAND

37

707-88-28270

BRACKET

38

707-88-26140

BAND

39

07372-21240

BOLT

40

01643-51232

WASHER

41

07283-33442

CLIP

42

01597-01009

NUT

43

01643-31032

WASHER

44

707-88-33040

CAP

45

07371-31049

FLANGE,SPLIT

46

07372-21035

BOLT

47

01643-51032

WASHER

48

07000-13038

O-RING

49

07378-11210

HEAD

50

07371-51260

FLANGE,SPLIT

51

01010-81245

BOLT

52

01643-31232

WASHER

|$57

707-99-69790

SERVICE KIT
