Запчасти Komatsu PC600LC-8 НАСОС ВЕНТИЛЯТОРА (/7)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-1U-00202

GEAR PUMP ASS'Y

|$4

708-1U-00212

PUMP ASS'Y

|$5

708-1U-01217

PUMP SUB ASS'Y

|$6

708-1U-04143

CASE ASS'Y

1

CASE,PUMP

2

PLUG

3

708-8E-16160

PLUG

4

07002-11023

O-RING

5

07040-12412

PLUG

6

07002-12434

O-RING

7

706-73-42370

O-RING

8

07000-B1009

O-RING

9

04020-01024

PIN

10

01010-61470

BOLT

11

01643-31445

WASHER

12

708-1U-11561

CAP,END

13

708-1W-42120

BEARING

14

708-1U-13461

BALL

15

708-1U-13450

CAM,ROCKER

16

04260-01270

BALL

17

708-1U-12120

SHAFT

18

708-1W-42110

BEARING

19

708-1W-42140

CASE,SEAL

20

708-1W-42130

SEAL,OIL

21

07000-B2060

O-RING

22

708-1W-05821

SPACER KIT

22

SPACER, 2.5MM

22

SPACER, 2.55MM

22

SPACER, 2.6MM

22

SPACER, 2.65MM

22

SPACER, 2.7MM

22

SPACER, 2.75MM

22

SPACER, 2.8MM

22

SPACER, 2.85MM

22

SPACER, 2.9MM

23

04065-06825

RING

24

708-1W-44311

SLEEVE

25

708-1W-44220

RING

26

708-1L-29340

ORIFICE
