Запчасти Komatsu PC600LC-8 МЕХАНИЗМ ПОВОРОТА (ЛЕВ.) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-75-01460

MOTOR ASS'Y

2

01010-81460

BOLT

3

01643-31445

WASHER

4

22U-26-21280

RING

5

07049-01822

PLUG

6

07042-30108

PLUG

7

21M-26-21170

CASE

8

06000-22222

BEARING

9

06000-22324

BEARING

10

207-26-54263

COVER

11

01010-81040

BOLT

12

01643-31032

WASHER

13

207-26-61210

SEAL

14

21M-26-11180

SHAFT

15

207-26-62150

COUPLING

16

207-26-54230

PLATE

17

205-32-51211

BOLT

18

20Y-27-22170

CARRIER

19

20Y-27-22140

GEAR

20

20Y-27-22220

BEARING

21

20Y-27-21250

WASHER

22

20Y-27-21230

PIN

23

20Y-27-21290

PIN

24

207-26-62190

GEAR

25

20Y-27-13310

WASHER

26

20Y-27-22240

WASHER

27

21M-26-11260

GEAR

28

21M-26-11150

CARRIER

29

21M-26-11140

GEAR

30

20Y-27-22210

BEARING

31

20Y-27-21240

WASHER

32

20Y-27-21220

PIN

33

20Y-27-21280

PIN

34

21M-26-11190

PLATE

35

21M-26-21130

GEAR

36

20Y-27-21310

WASHER

37

21M-26-11161

COVER

38

20Y-27-13281

BOLT

39

01643-31645

WASHER

40

21M-26-21230

BUTTON

40

208-27-61350

BUTTON

41

20Y-27-22280

O-RING

42

21M-26-11270

ELBOW

43

02896-11018

O-RING

44

02782-10628

ELBOW

45

02896-11018

O-RING

46

02762-006A4

HOSE

47

07730-50004

VALVE

48

07002-12434

O-RING

49

21M-26-21180

GAUGE

50

21M-26-21220

FILLER
