Запчасти Komatsu PC600LC-8 ЛЕВ. КРЫШКА(КАБИНА) (ДЛЯ ПРОТИВОВЕС REMOVER) ЧАСТИ КОРПУСА

1

21M-54-23910

FRAME

2

21M-54-15590

SEAL

3

21M-54-15610

SEAL

4

21M-54-15620

SEAL

5

21M-54-15630

SEAL

6

20Y-54-28170

BRACKET

7

01010-81230

BOLT

8

01643-31232

WASHER

9

205-54-51971

DOVE TAIL

9

205-54-51970

DOVE TAIL

10

01010-80616

BOLT

11

01643-30623

WASHER

12

21M-54-11730

PLATE

13

01010-81230

BOLT

14

01643-31232

WASHER

15

20Y-54-11611

STOPPER

16

01580-11008

NUT

17

20Y-54-29232

BAR

18

21M-54-21442

DUCT

19

21M-54-15550

SHEET

20

21M-54-21670

SHEET

21

01010-81230

BOLT

22

01643-31232

WASHER

23

21M-54-15570

SEAL

24

21M-54-15580

SEAL

25

21M-54-21431

COVER

26

198-54-41982

LOCK ASS'Y (WELDED)

27

20Y-54-28161

HINGE (WELDED)

28

21M-54-16512

SHEET

29

21M-54-21460

SHEET

30

21M-54-11760

PLATE

31

01010-81240

BOLT

32

01643-31232

WASHER

33

205-54-53550

DOVE TAIL

34

01010-80612

BOLT

35

01643-30623

WASHER

36

21M-54-21421

COVER

37

198-54-41982

LOCK ASS'Y (WELDED)

38

20Y-54-28161

HINGE (WELDED)

39

21M-54-16512

SHEET

40

21M-54-23480

SHEET

41

21M-54-21452

SHEET

42

21M-54-11760

PLATE

43

01010-81240

BOLT

44

01643-31232

WASHER

45

205-54-53550

DOVE TAIL

46

01010-80612

BOLT

47

01643-30623

WASHER

48

01010-81230

BOLT

49

01643-31232

WASHER
