Запчасти Komatsu PC600LC-7K ГИДР. БАК. (БАК И ФИЛЬТР.) ГИДРАВЛИКА

|1

21M-60-K1140

HYD. TANK ASS'Y

1

TANK

2

20Y-60-K1480

GAUGE

3

198-60-19820

VALVE

4

07040-13618

PLUG

5

207-60-61171

COVER

6

07000-15180

O-RING

7

01010-81225

BOLT

8

01643-31232

WASHER

|9

21M-60-11140

STRAINER ASS'Y

9

207-60-51200

STRAINER

10

21M-60-11150

ROD ASS'Y

11

12R-60-11230

SPRING

12

17A-60-11310

CAP ASS'Y

13

20Y-60-21470

ELEMENT

14

20Y-60-21460

NECK

15

20Y-60-21340

GASKET

16

01252-70516

BOLT

17

01601-20513

WASHER

18

07056-10045

STRAINER

19

04065-04718

RING

20

07270-61418

TUBE

21

07285-00155

CLIP

22

04434-51812

CLIP

23

01010-81225

BOLT

24

01643-31232

WASHER

25

7861-93-3320

SENSOR

26

21M-60-11240

CASE

27

205-60-71141

COVER

28

07000-15180

O-RING

29

01010-81230

BOLT

30

01643-31232

WASHER

31

07069-34057

SPRING

32

20Y-60-31131

VALVE ASS'Y

33

20Y-60-31140

STRAINER

34

209-60-77530

ELEMENT

35

21N-60-31240

POPPET

36

706-76-71190

SPRING

37

04065-05020

RING

38

207-60-51170

SPACER

39

07042-30211

PLUG

40

208-60-61321

BRACKET

41

01010-81025

BOLT

42

01643-31032

WASHER

43

07000-12095

O-RING

44

01010-81230

BOLT

45

175-54-34170

WASHER

46

07000-12060

O-RING

47

01010-81245

BOLT

48

01643-31232

WASHER
