Запчасти Komatsu PC600LC-7 СЪЕМ ПРОТИВОВЕСА CYLINDE (GROUND УСТАНОВКА ТИП)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XT400

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0G420

CYLINDER ASS'Y

1

707-13-18770

CYLINDER

2

707-76-11220

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

707-58-12530

ROD

5

707-76-11220

BUSHING

6

07145-00110

SEAL,DUST (KIT)

7

07000-15175

O-RING (KIT)

8

707-71-70340

PLUNGER

9

04260-00952

BALL

10

707-71-91230

CAP

11

707-27-18930

HEAD

12

195-63-93170

SEAL,DUST (KIT)

13

07179-13136

RING,SNAP

14

707-52-90980

BUSHING

15

07179-13126

RING,SNAP

16

707-51-12030

PACKING,ROD (KIT)

17

707-51-12640

RING,BUFFER (KIT)

18

707-35-91840

RING,BACK-UP (KIT)

19

01011-82400

BOLT

20

707-88-75410

WASHER

21

707-36-18520

PISTON

22

01310-01225

SCREW

23

707-44-18280

RING,PISTON (KIT)

24

707-39-18510

RING,WEAR (KIT)

25

707-44-18920

RING

26

07001-05110

RING,BACK-UP (KIT)

27

07000-15110

O-RING (KIT)

28

21M-46-14530

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-RING (KIT)

32

707-88-25790

BRACKET

33

707-88-21880

BAND

34

07372-21240

BOLT

35

01643-51232

WASHER

36

07283-33442

CLIP

37

01643-31032

WASHER

38

01597-01009

NUT

39

707-88-33040

CAP

40

07371-31049

FLANGE,SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|$47

707-99-68780

SERVICE KIT
