Запчасти Komatsu PC600LC-6KJ КАБИНА (ОСНОВ.) (ДЛЯ ЕС)(№-999) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

207-06-61510

BASE

2

20Y-06-24120

SWITCH ASS'Y

3

01641-21223

WASHER

4

569-06-61960

RELAY

5

01435-40610

BOLT

|5

01435-00610

BOLT

6

21M-06-13120

WIRING HARNESS

7

205-06-73180

FUSE¤ 15A,15A

8

283-06-16110

BOX

9

195-Z11-2290

COVER

10

283-06-16190

FUSE¤ 10A,10A

11

22W-06-13160

FUSE¤ 20A

12

20Y-06-24130

SWITCH

13

20Y-06-24270

CLIP

14

20Y-06-21460

CLIP

15

20Y-06-23960

CLIP

16

01023-10625

SCREW

17

20Y-979-2130

BOX ASS'Y

18

01435-41016

BOLT

|18

01435-01016

BOLT

19

20Y-979-2221

DUCT

20

01435-40610

BOLT

|20

01435-00610

BOLT

21

20Y-979-2231

DUCT

22

01435-40610

BOLT

|22

01435-00610

BOLT

23

20Y-979-2242

DUCT

24

01435-40610

BOLT

|24

01435-00610

BOLT

25

7827-11-1520

RESISTOR

26

01435-40820

BOLT

|26

01435-00820

BOLT

27

203-06-56230

BUZZER ASS'Y

28

01435-40610

BOLT

|28

01435-00610

BOLT

29

7834-20-5005

CONTROLLER¤GPC

|29

7834-20-5004

CONTROLLER

|29

7834-20-5003

CONTROLLER,GPC

30

01435-40880

BOLT

|30

01435-00880

BOLT

31

20Y-06-25130

RELAY BOX ASS'Y

32

01435-40630

BOLT

|32

01435-00630

BOLT

33

08051-00801

CLIP

34

20Y-06-23521

LOCK

35

01435-40820

BOLT

|35

01435-00820

BOLT

36

20Y-06-24220

SHEET
