Запчасти Komatsu PC600LC-6A ГИДР. БАК.(№-) ГИДРАВЛИКА

|1

21M-60-00140

HYDRAULIC TANK ASS'Y

1

TANK

2

203-60-31100

ELBOW ASS'Y

3

203-60-31160

TUBE

4

198-60-19820

VALVE

5

07040-13618

PLUG

6

207-60-61171

COVER

7

07000-15180

O-RING

8

01010-81225

BOLT

9

01643-31232

WASHER

|10

21M-60-11140

STRAINER ASS'Y

10

207-60-51200

STRAINER

11

21M-60-11150

ROD ASS'Y

12

12R-60-11230

SPRING

13

17A-60-11310

CAP ASS'Y

14

20Y-60-21470

ELEMENT

15

20Y-60-21460

NECK

16

20Y-60-21340

GASKET

17

01252-70516

BOLT

18

01601-20513

WASHER

19

07056-10045

STRAINER

20

04065-04718

RING

21

07270-61418

TUBE

22

07285-00155

CLIP

23

04434-51812

CLIP

24

01010-81225

BOLT

25

01643-31232

WASHER

26

7861-93-4210

SENSOR

27

01252-40612

BOLT

28

01641-20608

WASHER

29

7861-93-3320

SENSOR

30

21M-60-11130

CASE

31

208-60-61140

COVER

32

07000-15210

O-RING

33

01010-81235

BOLT

34

01643-31232

WASHER

35

07069-34057

SPRING

36

07069-05400

VALVE ASS'Y

37

07069-25400

STRAINER

38

208-60-61180

ELEMENT

39

21N-60-31240

POPPET

40

706-76-71190

SPRING

41

04065-05020

RING

42

207-60-51170

SPACER

43

07042-30211

PLUG

44

208-60-61321

BRACKET

45

01010-81030

BOLT

46

01643-31032

WASHER

47

07000-12095

O-RING

48

01010-81230

BOLT

49

01643-31232

WASHER

50

07000-12060

O-RING

51

01010-81245

BOLT

52

01643-31232

WASHER
