Запчасти Komatsu PC600LC-6A ОСНОВН. КЛАПАН (/8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

709-99-14701

CONTROL VALVE

|1

709-99-14700

CONTROL VALVE

|1

709-94-92390

BODY GROUP

1

BODY,VALVE

2

SPOOL

3

SPOOL SUB ASS'Y

4

SPOOL SUB ASS'Y

5

SPOOL

6

SPOOL

7

SPOOL

8

01643-30823

WASHER

9

01252-60825

BOLT

10

709-94-92510

SPRING

11

709-94-92520

SPRING

12

709-94-92530

RETAINER

13

709-94-92540

RETAINER

14

709-94-92770

RETAINER

15

04022-04008

PIN

16

709-94-91130

RETAINER

17

709-94-92890

RETAINER

18

709-94-91120

SPRING

19

709-94-92940

SPRING

20

709-94-92920

SPRING

21

709-94-92550

SPACER¤ 0.5MM

22

709-94-91760

SPACER¤ 1.0MM

23

709-94-92610

CASE

24

709-94-92560

CASE

25

709-94-91210

CASE

26

709-94-91220

CASE

27

07430-71380

O-RING

28

07000-12010

O-RING

29

01252-60820

BOLT

30

01252-60830

BOLT

31

07040-12012

PLUG

32

07002-12034

O-RING

33

709-94-92470

SPRING

34

709-94-92690

SPRING

35

709-94-91490

PLATE

36

709-94-91140

PLATE

37

07000-F2022

O-RING

38

01252-60820

BOLT

39

709-74-92220

PLUG

40

07002-13034

O-RING

41

08036-31210

CLIP
