Запчасти Komatsu PC600LC-6A ОСНОВН. КЛАПАН (/8) (-ЯC)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

709-99-14800

CONTROL VALVE

|$3

709-94-94400

BODY GROUP

1

BODY,VALVE

2

SPOOL

3

SPOOL SUB ASS'Y

4

SPOOL SUB ASS'Y

5

SPOOL

6

SPOOL

7

SPOOL

8

08036-31210

CLIP

9

01643-30823

WASHER

10

01252-60825

BOLT

11

709-94-92510

SPRING

12

709-94-92520

SPRING

13

709-94-92530

RETAINER

14

709-94-92540

RETAINER

15

709-94-92770

RETAINER

16

04022-04008

PIN

17

709-94-91130

RETAINER

18

709-94-92890

RETAINER

19

709-94-91120

SPRING

20

709-94-92940

SPRING

21

709-94-92920

SPRING

22

709-94-92550

SPACER, 0.5MM

23

709-94-91760

SPACER, 1.0MM

24

709-94-92610

CASE

25

709-94-92560

CASE

26

709-94-91210

CASE

27

709-94-91220

CASE

28

700-93-11660

O-RING

29

07000-52010

O-RING

30

01252-60820

BOLT

31

01252-60830

BOLT

32

07040-12012

PLUG

33

07002-52034

O-RING

34

709-94-92470

SPRING

35

709-94-92690

SPRING

36

709-94-91490

PLATE

37

709-94-91140

PLATE

38

07000-52022

O-RING

39

01252-60820

BOLT

40

709-74-92220

PLUG

41

07002-53034

O-RING
