Запчасти Komatsu PC600LC-6A-KJ ОХЛАЖД-Е (РАДИАТОР И МАСЛООХЛАДИТЕЛЬ)(№-) СИСТЕМА ОХЛАЖДЕНИЯ

1

21M-03-15110

RADIATOR CORE A.

2

20Y-03-22110

CAP

3

205-03-62660

PLUG

4

07000-11007

O-RING

5

20X-03-21170

HOSE

6

206-03-43340

CLIP

7

01010-81230

BOLT

8

01643-31232

WASHER

9

21M-03-15120

OIL COOLER ASS'Y

10

01010-81230

BOLT

11

01643-31232

WASHER

12

01010-81230

BOLT

13

01643-31232

WASHER

14

208-03-61250

SHEET

15

21M-03-11331

SEAL

16

21M-03-18210

SEAL

17

21M-03-18130

FRAME

18

21M-03-15220

FRAME

19

21M-03-18150

COVER

20

01010-81220

BOLT

21

01643-31232

WASHER

22

01010-81230

BOLT

23

01643-31232

WASHER

24

21M-03-11320

SEAL

25

21M-03-18220

SEAL

26

21M-03-18160

BRACKET

27

01010-81230

BOLT

28

01643-31232

WASHER

29

21M-03-18230

SEAL

30

21M-03-11490

SEAL

31

21M-03-18240

SEAL

32

21M-03-18290

SEAL

33

21M-03-15180

SEAL

34

21M-03-15170

SEAL

35

21M-03-15410

SHEET

36

21M-03-15420

SHEET

37

21M-03-15430

SHEET

38

21M-03-15440

SHEET

39

21M-03-15450

SHEET

40

21M-03-15470

SHEET

41

21M-03-15480

SHEET

42

21M-03-15490

SHEET

43

21M-03-15510

SHEET

44

21M-03-15520

SHEET

45

21M-03-11421

NET

46

21M-03-11411

NET

47

01434-10616

BOLT¤ WING

48

01643-30623

WASHER

49

21M-03-15130

SHROUD

50

21M-03-15310

BRACKET

51

01010-81025

BOLT

52

01643-31032

WASHER

53

21M-03-15320

BRACKET

54

01010-81025

BOLT

55

01643-31032

WASHER

56

21M-03-15330

BRACKET

57

01010-81025

BOLT

58

01643-31032

WASHER

59

209-03-77510

OIL COOLER ASS'Y

60

01010-81025

BOLT

61

01643-31032

WASHER
