Запчасти Komatsu PC600LC-6 ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

21M-63-X2121

ARM CYLINDER GROUP

|1

21M-63-02121

ARM CYLINDER ASS'Y

1

21M-63-62141

CYLINDER

2

707-76-12150

BUSHING

3

07145-00120

SEAL,DUST (KIT)

4

21M-63-62121

ROD

5

707-76-12520

BUSHING

6

07145-00125

SEAL,DUST (KIT)

7

707-71-32920

COLLAR

8

707-35-92020

RING,BACK-UP (KIT)

9

07000-15190

O-RING (KIT)

10

707-71-61500

PLUNGER

11

707-71-70310

PLUNGER

12

04260-00952

BALL

13

707-71-91230

CAP

14

707-27-20960

HEAD

15

198-63-93170

SEAL,DUST (KIT)

16

07179-14160

RING,SNAP

17

707-52-91170

BUSHING

18

707-51-14080

PACKING,ROD (KIT)

19

707-51-14630

RING,BUFFER (KIT)

20

707-35-92020

RING,BACK-UP (KIT)

21

07000-15190

O-RING (KIT)

22

01011-82705

BOLT

23

01643-32780

WASHER

24

707-36-20450

PISTON

25

01310-01232

SCREW

26

707-44-20180

RING,PISTON (KIT)

27

707-39-20820

RING,WEAR (KIT)

28

707-44-20910

RING

29

07001-05130

RING,BACK-UP (KIT)

30

07000-15130

O-RING (KIT)

31

21M-63-62172

TUBE

32

21M-63-62182

TUBE

33

01435-01055

BOLT

34

07000-13035

O-RING (KIT)

35

01010-81450

BOLT

36

01643-31445

WASHER

37

07000-13048

O-RING

38

707-88-21180

BRACKET

39

707-88-96110

BAND

40

21M-63-62192

BRACKET

41

707-88-96110

BAND

42

01010-81240

BOLT

43

01643-51232

WASHER

44

07283-23442

CLIP

45

07283-34346

CLIP

46

01643-31032

WASHER

47

01599-01011

NUT

48

07000-13038

O-RING

49

07378-11210

HEAD

50

07371-51260

FLANGE,SPLIT

51

01010-81245

BOLT

52

01643-31232

WASHER

|K

707-99-77140

SERVICE KIT
