Запчасти Komatsu PC600LC-6 ОСНОВН. НАСОС (/) (NO. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2L-00710

PUMP ASS'Y

|1

708-2L-00731

PUMP ASS'Y

|1

708-25-08890

SERVO VALVE ASS'Y,REAR

|1

708-25-08251

SERVO VALVE ASS'Y,REAR

|1

708-25-08450

SERVO VALVE SUB A.,REAR

|1

708-23-00421

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-15120

PISTON

4

708-25-15130

SEAT

5

708-25-55250

SPRING

6

708-25-25130

SPRING

7

708-23-15160

PLUG

8

708-23-15120

SEAT

9

07000-12018

O-RING

10

708-25-15150

COVER

11

01580-10806

NUT

12

01252-60616

BOLT

13

01602-20619

WASHER

14

708-25-55670

PLUG

15

07002-12034

O-RING

16

07239-12009

NUT

17

708-25-15180

SLEEVE

18

708-25-15280

SPOOL

19

708-25-15310

SPRING

20

708-25-15330

SPACER

21

708-25-15430

PLUG

22

708-25-15340

SCREW

23

07000-12012

O-RING

24

708-25-15250

COVER

25

01580-10806

NUT

26

01252-60616

BOLT

27

01602-20619

WASHER

28

708-25-15260

PLUG

29

07002-10823

O-RING

30

708-25-15270

ARM

31

708-25-15360

PIN

32

708-25-15370

WASHER

33

708-25-15380

E-RING
