Запчасти Komatsu PC600LC-6 КОНЕЧНАЯ ПЕРЕДАЧА(№-) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

1

706-88-01101

MOTOR ASS'Y

|$4

17M-27-00102

FLOATING SEAL ASS'Y

2

RING

3

O-RING

4

21M-27-11210

HUB

5

208-27-62110

BEARING

6

208-27-51212

COVER

7

01010-81240

BOLT

8

01643-31232

WASHER

9

21M-27-11280

O-RING

10

21M-27-00110

SPACER ASS'Y

10

SPACER, 3.5MM

10

SPACER, 3.25MM

10

SPACER, 3.3MM

10

SPACER, 3.35MM

10

SPACER, 3.4MM

10

SPACER, 3.45MM

10

SPACER, 3.55MM

11

21M-27-11290

RETAINER

12

208-27-52311

BOLT

13

21M-27-11380

BOLT

14

21M-27-11180

CARRIER

15

21M-27-11140

GEAR

16

21M-27-11230

BEARING

17

21M-27-11260

THRUST WASHER

18

21M-27-11250

PIN

19

20Y-27-21290

PIN

20

207-27-52270

SPACER

21

21M-27-11130

GEAR

22

21M-27-11270

THRUST WASHER

23

21M-27-11150

GEAR

24

21M-27-11160

GEAR

25

21M-27-11170

CARRIER

26

21M-27-11120

GEAR

27

21M-27-11411

BEARING

28

20Y-27-21250

WASHER

29

21M-27-11240

PIN

30

20Y-27-21280

PIN

31

21M-27-11110

SHAFT

32

20Y-27-11250

SPACER

33

207-27-61280

BUTTON

34

21M-27-11190

COVER

35

208-27-52341

BOLT

36

01643-31845

WASHER

37

07049-01215

PLUG

38

07044-12412

PLUG

39

07002-12434

O-RING

40

21M-27-11220

SPROCKET

41

01010-82265

BOLT

42

01643-32260

WASHER

43

01010-62490

BOLT

44

01643-32460

WASHER

45

21M-30-12340

GUARD,L.H.

46

01010-81640

BOLT

47

01643-31645

WASHER

48

21M-30-12350

GUARD,R.H.
