Запчасти Komatsu PC600-8R1 ПРЯМАЯ ЛОПАТА БЛОК, ЦИЛИНДР РУКОЯТИ(№7-) ПРЯМАЯ ЛОПАТА БЛОК

|$0

707-01-0E890

Cylinder Assembly

1

707-13-20410

Cylinder

2

707-58-14220

Rod, Piston

3

707-76-12520

Bushing

4

07145-00125

Seal, Dust, (Kit : K08)

5

707-76-12520

Bushing

6

07145-00125

Seal, Dust, (Kit : K08)

7

707-71-60350

Plunger

8

04260-01270

Ball

9

707-71-91510

Cap

10

707-27-20960

Head, Cylinder

11

707-56-14740

Seal, Dust, (Kit : K08)

12

07179-14160

Ring, Snap

13

707-51-14080

Packing, Rod, (Kit : K08)

14

707-51-14640

Ring, Buffer, (Kit : K08)

15

707-52-91171

Bushing

16

07000-15190

O-ring, (Kit : K08)

17

707-35-92020

Ring, Back-up, (Kit : K08)

18

01011-82705

Bolt

19

01643-32780

Washer

20

707-36-20450

Piston

21

707-44-20180

Ring, Piston, (Kit : K08)

22

707-39-20820

Ring, Wear, (Kit : K08)

23

707-44-20910

Ring

24

07000-15130

O-ring, (Kit : K08)

25

07001-05130

Ring, Back-up, (Kit : K08)

26

01310-01232

Screw

27

707-86-12170

Tube

28

01010-81450

Bolt

29

01010-81245

Bolt

30

01643-31232

Washer

31

07000-13038

O-ring, (Kit : K08)

32

707-88-25030

Bracket

33

707-88-96110

Band

34

07372-21240

Bolt

35

01643-51232

Washer

36

07282-13411

Clip

37

01010-81020

Bolt

38

01643-31032

Washer

39

707-88-22000

Bracket

40

07283-33442

Clip, Pipe

41

01597-01009

Nut

42

01643-31032

Washer

43

07378-11210

Head

44

07371-51260

Flange, Split

45

705-17-04980

Washer
