Запчасти Komatsu PC600-8R1 МЕХАНИЗМ ПОВОРОТА И МОТОР, ПОСТАВЛЯЕМЫЕ ЧАСТИ (№7-) МЕХАНИЗМ ПОВОРОТА И МОТОР

1

21M-26-21170

Case

2

06000-22222

Bearing

3

06000-22324

Bearing

4

207-26-54263

Cover

5

01010-81040

Bolt

6

01643-31032

Washer

7

207-26-61210

Seal

8

21M-26-11180

Shaft

9

207-26-62150

Coupling

10

207-26-54230

Plate

11

205-32-51211

Bolt

12

20Y-27-22170

Carrier

13

20Y-27-22140

Gear

14

20Y-27-22220

Bearing

15

20Y-27-21250

Washer, Thrust

16

20Y-27-21230

Pin

17

20Y-27-21290

Pin

18

207-26-62190

Gear

19

20Y-27-13310

Washer, Thrust

20

20Y-27-22240

Washer, Thrust

21

21M-26-11260

Gear

22

21M-26-11150

Carrier

23

21M-26-11140

Gear

24

20Y-27-22210

Bearing

25

20Y-27-21240

Washer, Thrust

26

20Y-27-21220

Pin

27

20Y-27-21280

Pin

28

21M-26-11190

Plate

29

21M-26-21130

Gear

30

20Y-27-21310

Washer

31

21M-26-11161

Cover

32

20Y-27-22280

O-ring

33

20Y-27-13281

Bolt

34

01643-31645

Washer

35

208-27-61350

Button

36

20Y-26-22411

Cover

37

01010-81445

Bolt

38

01643-31445

Washer, Flat

39

07042-30617

Plug, Taper

40

07042-30108

Plug

41

07040-12412

Plug

42

07002-12434

O-ring
