Запчасти Komatsu PC600-8R1 КАБИНА, КЛАПАН PPCДЛЯ ХОД (№7-) КАБИНА, EOPS КАБИНА, ПРАВ. И ЗАДН. ФИКС. ОКНА, AM-FM РАДИО ДЛЯ АЗИИ, KOMTRAX

|$0

702-16-04270

Valve Assembly, PPC

1

Valve Body

2

Valve

3

702-16-51140

Shim, T=0.30mm

4

702-16-53420

Spring

5

702-16-53140

Retainer

6

702-16-54420

Spring

7

702-16-53170

Piston

8

702-16-71150

Seal

9

702-16-71160

Seat

10

Case

11

Lever

12

Shaft

13

702-16-73640

Plate

14

01010-80855

Bolt

15

01643-30823

Washer

16

01010-80816

Bolt

17

702-16-54331

Washer, T=1.60mm

17

702-16-54341

Washer, T=1.30mm

17

702-16-54351

Washer, T=1.00mm

17

702-16-56380

Washer, T=1.90mm

17

702-16-56390

Washer, T=2.20mm

18

Pin, Spring

19

Bushing

20

O-ring

21

702-16-73610

Damper Assembly

22

01023-10306

Screw

23

Pin

24

04022-04016

Pin, Dowel

25

Plug

26

Plug

27

07040-11209

Plug

28

07002-11223

O-ring

29

Ball

30

Plug

31

Seat
