Запчасти Komatsu PC600-8R МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

706-8L-01010

MOTOR ASS'Y

|$3

706-88-02100

MOTOR ASS'Y

1

706-88-40380

O-RING

2

07000-12012

O-RING

3

706-88-40310

BOLT

4

706-8L-41520

SHAFT,DRIVE

4

706-88-40670

SHAFT,DRIVE

5

706-88-40870

BEARING

6

706-88-40890

BEARING

7

706-88-40820

RETAINER

8

706-88-05010

SPACER KIT

8

SPACER, 1.6MM

8

SPACER, 1.7MM

8

SPACER, 1.8MM

9

04064-07525

RING,SNAP

10

708-8K-12141

SEAL,OIL

11

706-88-40710

HOUSING

12

07000-02135

O-RING

13

04071-00140

RING,SNAP

14

706-8L-41370

SHAFT,CENTER

14

706-88-40280

SHAFT,CENTER

15

706-8L-41270

RING,CENTER

15

706-88-40230

RING,CENTER

16

706-8L-41380

SPRING

16

706-88-40060

SPRING

|$28

706-88-05030

RETAINER KIT

17

706-8L-41260

RETAINER

17

706-88-40860

RETAINER

18

708-23-12350

SCREW

18

708-23-12350

SCREW

19

706-8L-41610

PISTON SUB ASS'Y

20

706-88-90140

PLATE

21

706-88-90150

DISC

22

706-8L-91010

PISTON,BRAKE

22

706-88-90280

PISTON,BRAKE

23

07000-15240

O-RING

24

706-88-90130

RING,BACK-UP

25

07000-15270

O-RING

26

07001-05270

RING,BACK-UP

27

706-88-90420

SPRING
