Запчасти Komatsu PC600-8R ЦИЛИНДР РУКОЯТИ(ДЛЯ ПОГРУЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XU280

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0E890

CYLINDER ASS'Y

1

707-13-20410

CYLINDER

2

707-76-12520

BUSHING

3

07145-00125

SEAL,DUST (KIT)

4

707-27-20960

HEAD,CYLINDER

5

707-51-14080

PACKING,ROD (KIT)

6

707-51-14640

RING,BUFFER (KIT)

7

707-52-91170

BUSHING

8

198-63-93170

SEAL,DUST (KIT)

9

07179-14160

RING,SNAP

10

07000-15190

O-RING (KIT)

11

707-35-92020

RING,BACK-UP (KIT)

12

01011-82705

BOLT

13

01643-32780

WASHER

14

707-58-14220

ROD,PISTON

15

707-76-12520

BUSHING

16

07145-00125

SEAL,DUST (KIT)

17

707-36-20450

PISTON

18

07000-15130

O-RING (KIT)

19

07001-05130

RING,BACK-UP (KIT)

20

707-44-20910

RING

21

707-39-20820

RING,WEAR (KIT)

22

707-44-20180

RING,PISTON (KIT)

23

707-71-60350

PLUNGER

24

04260-01270

BALL

25

707-71-91520

CAP

26

01310-01232

SCREW

27

707-86-12170

TUBE

28

07000-13038

O-RING (KIT)

29

01435-01245

BOLT

30

707-88-96110

BAND

31

707-88-22000

BRACKET

32

707-88-25030

BRACKET

33

01435-01235

BOLT

34

07283-33442

CLIP

35

01597-01009

NUT

36

01643-31032

WASHER

37

07282-03411

CLAMP

38

01435-01020

BOLT

39

07000-13038

O-RING

40

07378-11210

HEAD

41

07371-51260

FLANGE

42

01010-81245

BOLT

43

01643-31232

WASHER

|$48

707-99-77160

SERVICE KIT
