Запчасти Komatsu PC600-8R ЦИЛИНДР СТРЕЛЫ(ДЛЯ ПОГРУЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XU260

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XU270

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0E870

CYLINDER ASS'Y

1

707-13-18730

CYLINDER

2

707-76-11160

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

07043-00108

PLUG

5

07020-00000

FITTING,GREASE

6

707-27-18970

HEAD,CYLINDER

7

707-51-13030

PACKING,ROD (KIT)

8

707-51-13640

RING,BUFFER (KIT)

9

707-52-91070

BUSHING

10

707-56-13520

SEAL,DUST (KIT)

11

07179-14146

RING

12

07000-15175

O-RING (KIT)

13

707-35-91840

RING,BACK-UP (KIT)

14

01011-82400

BOLT

15

707-88-75410

WASHER

16

707-58-12490

ROD,PISTON

17

707-76-12530

BUSHING

18

07145-00125

SEAL,DUST (KIT)

19

707-36-18530

PISTON

20

07000-15120

O-RING (KIT)

21

07001-05120

RING,BACK-UP (KIT)

22

707-44-18920

RING

23

707-39-18830

RING,WEAR (KIT)

24

707-44-18280

RING,PISTON (KIT)

25

01310-01225

SCREW

26

707-86-12150

TUBE,L.H.

26

707-86-12160

TUBE,R.H.

27

707-86-12130

TUBE,L.H.

27

707-86-12140

TUBE,R.H.

28

07000-13035

O-RING (KIT)

29

01435-01055

BOLT

30

707-88-21090

BAND

31

707-88-25010

BRACKET

32

01435-01235

BOLT

33

07283-33442

CLIP

34

01597-01009

NUT

35

01643-31032

WASHER

36

707-88-33040

CAP

37

07371-31049

FLANGE

38

07372-21035

BOLT

39

01643-51032

WASHER

|$48

707-99-69700

SERVICE KIT
