Запчасти Komatsu PC600-8E0 МЕХАНИЗМ ПОВОРОТА И МОТОР, ВНУТР. ЧАСТИ, МОТОР ПОВОРОТА (/) (№-) МЕХАНИЗМ ПОВОРОТА И МОТОР

|$0

706-75-01461

Motor Assembly

|$1

706-75-01460

Motor Assembly

|$2

706-75-03451

Motor Subassembly

|$3

706-75-03450

Motor Subassembly

1

706-75-43680

Shaft, Drive

2

706-75-43880

Bearing

3

706-75-43810

Spacer

4

706-7E-11260

Spring

5

706-7E-11270

Seat

6

706-76-40890

Bearing

7

706-75-05040

Spacer Kit

7

Spacer, T=3.1mm

7

Spacer, T=3.4mm

7

Spacer, T=3.7mm

8

04064-04518

Ring, Snap

9

706-75-43410

Seal, Oil

9

706-7E-11280

Seal, Oil

10

706-7G-41910

Spacer

11

04065-06220

Ring, Snap

12

706-75-43190

Block, Cylinder

13

706-75-43841

Plate, Valve

14

706-75-43750

Pin, Dowel

15

706-75-43120

Shaft,Center

16

706-75-43130

Ring,Center

17

706-75-43140

Spring

17

706-75-05020

Retainer Kit

18

Retainer

19

Screw

20

706-75-43160

Piston Subassembly

21

706-75-92130

Plate

22

706-75-92340

Plate

23

706-75-92350

Disk

24

706-75-92380

Piston, Brake

25

706-75-92390

Ring, Brake

26

07000-B2145

O-ring

26

07000-12145

O-ring

27

708-1W-49170

O-ring

27

706-75-92310

O-ring

28

706-75-92360

Spring
