Запчасти Komatsu PC600-8E0 ПРЯМАЯ ЛОПАТА БЛОК, ЦИЛИНДР КОВША, ПРАВ. (№-) ПРЯМАЯ ЛОПАТА БЛОК

|$0

707-01-0E900

Cylinder Assembly

1

707-13-16810

Cylinder

2

707-58-11450

Rod, Piston

3

707-46-11510

Bushing

4

07043-00108

Plug, Taper

5

707-76-12530

Bushing

6

07145-00125

Seal, Dust, (Kit : K09)

7

707-27-16920

Head, Cylinder

8

07179-13126

Ring, Snap

9

707-56-11740

Seal, Dust, (Kit : K09)

10

707-52-90851

Bushing

11

707-51-11030

Packing, Rod, (Kit : K09)

12

707-51-11640

Ring, Buffer, (Kit : K09)

13

07000-15150

O-ring, (Kit : K09)

14

707-35-91640

Ring, Back-up, (Kit : K09)

15

01010-82085

Bolt

16

707-88-75310

Washer

17

707-36-16580

Piston

18

707-44-16180

Ring, Piston, (Kit : K09)

19

707-39-16120

Ring, Wear, (Kit : K09)

20

707-44-16910

Ring

21

07000-15100

O-ring, (Kit : K09)

22

07001-05100

Ring, Back-up, (Kit : K09)

23

01310-01216

Screw

24

707-86-12190

Tube

25

707-88-22200

Bracket

26

707-88-21660

Band

27

07372-21240

Bolt

28

01643-51232

Washer

29

07282-03411

Clamp

30

01010-81020

Bolt

31

01643-31032

Washer

32

707-88-22100

Bracket

33

707-88-33040

Cap

34

07371-31049

Flange, Split

35

07372-21035

Bolt

36

01643-51032

Washer

37

01643-31032

Washer

38

07283-33442

Clip, Pipe

39

07000-13038

O-ring, (Kit : K09)

40

01597-01009

Nut

41

07371-51260

Flange, Split

42

707-88-33050

Cap

43

01010-81245

Bolt

44

01643-31232

Washer
