Запчасти Komatsu PC600-8 ВСАСЫВ. ЛИНИИ H ГИДРАВЛИКА

1

21M-62-21131

TUBE

2

07000-12080

O-RING

3

07372-21240

BOLT

4

01643-51232

WASHER

5

21M-62-21141

TUBE

6

07000-12060

O-RING

7

07372-21240

BOLT

8

01643-51232

WASHER

9

07260-07428

HOSE

10

21N-62-37921

CLAMP

11

07260-04722

HOSE

12

21M-62-21550

CLAMP

13

21M-62-21122

TUBE

14

07040-12412

PLUG

15

07002-12434

O-RING

16

198-60-19820

VALVE

17

07040-13618

PLUG

18

07373-31400

SPACER

19

07000-13048

O-RING

20

07298-01407

HOSE

21

07000-13048

O-RING

22

07371-31465

FLANGE

23

07372-21245

BOLT

24

01643-51232

WASHER

25

07372-21240

BOLT

26

01643-51232

WASHER

27

21M-62-21110

TUBE

28

07000-12120

O-RING

29

01010-81245

BOLT

30

01643-31232

WASHER

31

209-62-41150

HOSE

32

209-62-41341

CLAMP

33

21M-62-21150

BRACKET

34

01010-81235

BOLT

35

01643-31232

WASHER

36

07283-31193

CLIP

37

01597-01211

NUT

38

01643-31232

WASHER

39

21M-62-21160

BRACKET

40

195-33-11220

SPACER

41

01010-81250

BOLT

42

01643-31232

WASHER
