Запчасти Komatsu PC600-8 ЦИЛИНДР РУКОЯТИ(С ПРЕДОТВРАЩЕНИЕМ СМЕЩЕНИЯ КЛАПАН) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XR770

CYLINDER GROUP, (FINAL COATING)

|1

707-01-0J650

ARM CYLINDER ASSEMBLY

1

707-13-20470

CYLINDER

2

707-76-12150

BUSHING

3

07145-00120

SEAL, DUST (KIT)

4

707-58-14330

ROD

5

707-76-12520

BUSHING

6

07145-00125

SEAL, DUST (KIT)

7

707-71-32920

COLLAR

8

707-35-92020

RING, BACK-UP (KIT)

9

07000-15190

O-RING (KIT)

10

707-71-61510

PLUNGER

11

707-71-70840

PLUNGER

12

04260-00952

BALL

13

707-71-91230

CAP

14

707-27-20590

HEAD

15

198-63-93170

SEAL, DUST (KIT)

16

07179-14160

RING, SNAP

17

707-52-91170

BUSHING

18

707-75-14110

RING

19

707-51-14080

PACKING, ROD (KIT)

20

707-51-14650

RING, BUFFER (KIT)

21

707-35-92020

RING, BACK-UP (KIT)

22

07000-15190

O-RING (KIT)

23

01011-82705

BOLT

24

01643-32780

WASHER

25

707-36-20450

PISTON

26

01310-01232

SCREW

27

707-44-20150

RING, PISTON (KIT)

28

707-39-20020

RING, WEAR (KIT)

29

707-44-20910

RING

30

07001-05130

RING, BACK-UP (KIT)

31

07000-15130

O-RING (KIT)

32

707-88-28360

BRACKET

33

707-88-26130

BAND

34

707-88-28370

BRACKET

35

707-88-26130

BAND

36

07372-21240

BOLT

37

01643-51232

WASHER

38

07000-13038

O-RING

39

07378-11210

HEAD

40

07371-51260

FLANGE, SPLIT

41

01010-81245

BOLT

42

01643-31232

WASHER

43

707-88-33040

CAP

44

07371-31049

FLANGE, SPLIT

45

07372-21035

BOLT

46

01643-51032

WASHER

|K

707-99-76300

SERVICE KIT
