Запчасти Komatsu PC600-8 НАСОС ВЕНТИЛЯТОРА (/7) (№K8-) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-1U-00202

GEAR PUMP ASSEMBLY

|1

708-1U-00212

PUMP ASSEMBLY

|1

708-1U-01217

PUMP SUB ASSEMBLY

|1

708-1U-04143

CASE ASSEMBLY

1

CASE, PUMP

2

PLUG

3

708-8E-16160

PLUG

4

07002-11023

O-RING

5

07040-12412

PLUG

6

07002-12434

O-RING

7

706-73-42370

O-RING

8

07000-B1009

O-RING

9

04020-01024

PIN

10

01010-61470

BOLT

11

01643-31445

WASHER

12

708-1U-11561

CAP, END

13

708-1W-42120

BEARING

14

708-1U-13461

BALL

15

708-1U-13450

CAM, ROCKER

16

04260-01270

BALL

17

708-1U-12120

SHAFT

18

708-1W-42110

BEARING

19

708-1W-42140

CASE, SEAL

20

708-1W-42130

SEAL, OIL

21

07000-B2060

O-RING

22

708-1W-05821

SPACER KIT

|$28

SPACER, 2.5MM

|$29

SPACER, 2.55MM

|$30

SPACER, 2.6MM

|$31

SPACER, 2.65MM

|$32

SPACER, 2.7MM

|$33

SPACER, 2.75MM

|$34

SPACER, 2.8MM

|$35

SPACER, 2.85MM

|$36

SPACER, 2.9MM

23

04065-06825

RING

24

708-1W-44311

SLEEVE

25

708-1W-44220

RING

26

708-1L-29340

ORIFICE
