Запчасти Komatsu PC600-8 ПРАВ. КОРПУС (№K8-) M ЧАСТИ КОРПУСА

1

21M-54-22310

COVER

2

20Y-54-74132

COVER

3

20Y-54-74161

HINGE (WELDED)

4

421-54-11372

LOCK ASSEMBLY (WELDED)

5

20Y-54-29680

SHEET

6

20Y-54-29660

SEAL

7

203-54-56630

ROD

8

21M-54-14330

SHEET

9

01643-30623

WASHER

10

04050-11612

PIN

11

01010-81020

BOLT

12

01643-31032

WASHER

13

20Y-00-42140

PLATE

14

209-00-41550

PLATE

15

01010-81230

BOLT

16

175-54-34170

WASHER

17

21M-54-24610

COVER

|17

21M-54-22411

COVER

18

21M-54-24620

COVER

|18

21M-54-22421

COVER

19

198-54-41982

LOCK ASSEMBLY (WELDED)

20

205-46-63360

HINGE (WELDED)

21

01010-81250

BOLT

22

01643-31232

WASHER

23

20Y-54-29651

BRACKET

24

01010-81225

BOLT

25

01643-31232

WASHER

26

203-54-56630

ROD

27

01643-30623

WASHER

28

04050-11612

PIN

29

21M-54-16780

SHEET

30

21M-54-32430

COVER

31

195-33-11220

SPACER

32

01010-81225

BOLT

33

01643-31232

WASHER

34

209-00-41560

PLATE

35

01010-81275

BOLT

36

01643-31232

WASHER

37

195-03-11570

SHIM, 1.0MM
