Запчасти Komatsu PC600-8 НАСОС СМАЗКИ (СМАЗ. GUN)(№-78) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC600-8 - НАСОС СМАЗКИ (СМАЗ. GUN)(№-78) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
26
26
27
27
27
28
28
28
29
29
29
30
30
30
31
31
32
33
34

Артикул

Название

Примечание

Количество

|$1

209-68-11230

GREASE GUN ASS'Y

|$2

209-68-11610

GUN ASS'Y

|$3

YU802732

GUN ASS'Y

1

YU683201

RIVET

2

YU711351

LINK

3

YU711444

NUT

4

YU772160

PACKING

5

YU711357

ROD

6

YU711352

GUN

7

YU630314

BALL

8

YU711445

HOLDER

9

YU711446

SPRING

10

YU640011

O-RING

11

YU710971

UNION

12

YU711750

BOLT

13

YU627641

NUT

14

YU711354

LEVER

15

YU713638

PLATE

|$19

209-68-11640

COUPLER ASS'Y

|$20

YU800702

NOZZLE ASS'Y

|$21

YU800573

CHUCK ASS'Y

16

YU702450

TOOTH

17

209-68-11650

CAP

17

YU702449

COVER

18

YU702451

NOZZLE

19

YU770263

PACKING

20

YU702453

SPRING

21

YU702468

BODY

22

YU702452

WASHER

23

YU702454

WASHER

24

209-68-11630

NOZZLE

24

YU703344

NOZZLE

|$33

209-68-11620

SWIVEL JOINT ASS'Y

|$34

YU802910

SWIVEL JOINT ASS'Y

25

YU711732

NIPPLE

26

YU711731

NUT

27

YU580300

SPACER

28

YU711730

RETAINER

29

YU682988

BACK-UP RING

30

YU640003

O-RING

31

YU711729

HOUSING

32

YU711728

HOUSING

33

YU712212

NIPPLE

34

209-68-51220

ADAPTER

Выбрано товаров: 44
