Запчасти Komatsu PC600-7 ЛЕВ. КРЫШКА(КАБИНА) (ДЛЯ ЕС)(№87-) ЧАСТИ КОРПУСА

1

205-54-51970

DOVE TAIL

2

205-54-53550

DOVE TAIL

3

20Y-54-11611

STOPPER

4

20Y-54-28170

BRACKET

5

20Y-54-29232

BAR

6

21M-54-11730

PLATE

7

21M-54-11760

PLATE

8

21M-54-12310

SEAL

9

21M-54-12320

SEAL

10

21M-54-12330

SEAL

11

21M-54-15640

SEAL

12

21M-54-12350

SEAL

13

21M-54-15650

SEAL

14

21M-54-15511

FRAME

15

21M-54-15521

COVER

16

198-54-41982

LOCK ASS'Y (WELDED)

17

203-54-62180

HINGE (WELDED)

18

21M-54-15531

COVER

19

198-54-41982

LOCK ASS'Y (WELDED)

20

203-54-62180

HINGE (WELDED)

|$23

21M-54-17330

DUCT

21

DUCT

22

21M-54-17490

SHEET

23

21M-54-15550

SHEET

24

21M-54-15561

SHEET

25

21M-54-15570

SEAL

26

21M-54-15580

SEAL

27

01010-80612

BOLT

28

01643-30623

WASHER

29

01010-80616

BOLT

30

01643-30623

WASHER

31

01010-81230

BOLT

32

01643-31232

WASHER

33

01010-81240

BOLT

34

01643-31232

WASHER

35

01580-11008

NUT

36

21M-54-15590

SEAL

37

21M-54-15610

SEAL

38

21M-54-15620

SEAL

39

21M-54-15630

SEAL

40

21M-54-15660

SPACER

41

01010-81235

BOLT

42

01643-31232

WASHER

43

21M-54-16512

SHEET

44

21M-54-16532

SHEET

45

21M-54-16561

SHEET

46

21M-54-16522

SHEET
