Запчасти Komatsu PC600-6A ЛИНИЯ ПОДАЧИS (НАСОС - ФИЛЬТР.) (ДЛЯ C/W REMOVER) ГИДРАВЛИКА

1

21M-62-11750

HOSE

2

07000-13025

O-RING

3

07371-30640

FLANGE

4

07372-21035

BOLT

5

01643-51032

WASHER

6

21M-62-18130

BRACKET

7

21M-62-11741

BRACKET

8

01010-81230

BOLT

9

01643-31232

WASHER

10

07283-32244

CLIP

11

07283-52232

SEAT

12

01597-01009

NUT

13

01643-31032

WASHER

14

21M-62-11121

BLOCK

15

07000-13032

O-RING

16

209-62-61310

NIPPLE ASS'Y

17

209-62-61330

O-RING

18

21M-62-11110

BLOCK

19

07000-13032

O-RING

|$29

21M-62-18110

VALVE ASS'Y

20

207-60-31730

PIN

21

20Y-970-3350

FLANGE

22

BLOCK

23

209-62-75221

SHAFT

23

21M-62-18150

SHAFT

24

01010-81025

BOLT

24A

01643-31032

WASHER

25

01010-81040

BOLT

26

01643-31032

WASHER

27

04025-00412

PIN

28

07000-13042

O-RING

29

07000-13048

O-RING

30

07000-13032

O-RING

31

209-62-61310

NIPPLE ASS'Y

32

209-62-61330

O-RING

33

01011-81000

BOLT

34

01643-31032

WASHER

34A

07235-10315

ELBOW

34B

07002-12034

O-RING

|$54

21M-60-11301

FILTER ASS'Y

35

21M-60-11311

CASE

36

CASE

37

01010-81285

BOLT

38

01643-51232

WASHER

39

07000-12055

O-RING

40

07000-13038

O-RING

41

07001-02055

RING

42

07002-11023

O-RING

43

07040-11007

PLUG

44

07063-21200

ELEMENT

45

01010-81235

BOLT

46

01643-31232

WASHER

47

21M-62-11621

BRACKET

48

01010-81250

BOLT

49

175-54-34170

WASHER

50

21M-62-12160

BRACKET

50

21M-62-11610

BRACKET

51

01010-81680

BOLT

52

01643-31645

WASHER
