Запчасти Komatsu PC600-6A ЦИЛИНДР КОВША (ДЛЯ ПОГРУЗ.)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XU290

CYLINDER GROUP,L.H.

G-1

707-01-XU300

CYLINDER GROUP,R.H.

|$3

707-01-0E900

BUCKET CYLINDER A.

1

707-13-16810

CYLINDER

2

707-46-11510

BUSHING

3

07043-00108

PLUG

4

707-27-16920

HEAD

5

707-51-11030

PACKING,ROD (KIT)

6

707-51-11640

RING,BUFFER (KIT)

7

707-52-90850

BUSHING

8

198-63-94170

SEAL,DUST (KIT)

9

07179-13126

RING,SNAP

10

07000-15150

O-RING (KIT)

11

707-35-91640

RING,BACK-UP (KIT)

12

01010-82085

BOLT

13

707-88-75310

WASHER

14

707-58-11450

ROD

15

707-76-12530

BUSHING

16

07145-00125

SEAL,DUST (KIT)

17

07043-00108

PLUG

18

707-36-16580

PISTON

19

01310-01216

SCREW

20

707-44-16180

RING,PISTON (KIT)

21

707-39-16120

RING,WEAR (KIT)

22

707-44-16910

RING

23

07001-05100

RING,BACK-UP (KIT)

24

07000-15100

O-RING (KIT)

25

707-86-12180

TUBE,L.H.

25

707-86-12190

TUBE,R.H.

26

07000-13038

O-RING (KIT)

27

01435-01245

BOLT

28

707-88-22200

BRACKET

29

707-88-22100

BRACKET

30

707-88-21660

BAND

31

01435-01235

BOLT

32

07283-33442

CLIP

33

01597-01009

NUT

34

01643-31032

WASHER

35

07282-03411

CLAMP

36

01435-01020

BOLT

37

707-88-33040

CAP

38

07371-31049

FLANGE,SPLIT

39

07372-21035

BOLT

40

01643-51032

WASHER

|$46

707-99-67830

SERVICE KIT
