Запчасти Komatsu PC600-6 ЦИЛИНДР КОВША ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

21M-63-X2131

BUCKET CYLINDER G.

|1

21M-63-02131

BUCKET CYLINDER A.

1

21M-63-72141

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

21M-63-72120

ROD

6

707-76-11130

BUSHING

7

07145-00110

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

07043-00108

PLUG

10

707-71-32930

COLLAR

11

707-27-18960

HEAD

12

195-63-93170

SEAL,DUST (KIT)

13

07179-13136

RING,SNAP

14

707-52-90980

BUSHING

15

707-51-12030

PACKING,ROD (KIT)

16

707-51-12630

RING,BUFFER (KIT)

17

707-35-91840

RING,BACK-UP (KIT)

18

07000-15175

O-RING (KIT)

19

01011-82400

BOLT

20

707-88-75410

WASHER

21

707-71-61320

PLUNGER

22

707-36-18520

PISTON

23

01310-01225

SCREW

24

707-44-18280

RING,PISTON (KIT)

25

707-39-18830

RING,WEAR (KIT)

26

707-44-18920

RING

27

07001-05110

RING,BACK-UP (KIT)

28

07000-15110

O-RING (KIT)

29

21M-63-72171

TUBE

30

21M-63-72181

TUBE

31

01435-01055

BOLT

32

07000-13035

O-RING (KIT)

33

707-88-22030

BRACKET

34

707-88-21050

BAND

35

209-63-73592

BRACKET

36

707-88-21060

BAND

37

01010-81240

BOLT

38

01643-51232

WASHER

39

07283-23442

CLIP

40

01599-01011

NUT

41

01643-31032

WASHER

42

707-88-33040

CAP

43

07371-31049

FLANGE,SPLIT

44

07372-21035

BOLT

45

01643-51032

WASHER

46

07000-13038

O-RING

47

07378-11210

HEAD

48

07371-51260

FLANGE,SPLIT

49

01010-81245

BOLT

50

01643-31232

WASHER

|K

707-99-68560

SERVICE KIT
