Запчасти Komatsu PC600-6 СЕРДЦЕВИНА БЛОК В СБОРЕ (С КОНДИЦИОНЕРОМ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

ND445800-9057

CORE UNIT ASS'Y

1

ND245420-4096

CASE

2

ND447600-0651

EVAPORATOR

3

ND949142-0030

O-RING

4

ND077500-0710

THERMISTOR

5

ND246690-2840

CLAMP

6

ND447500-3540

VALVE

6

ND447500-1390

VALVE

7

ND446870-1990

TUBE

8

ND949142-0030

O-RING

9

ND949142-0010

O-RING

10

ND949046-2150

BOLT

11

ND146984-5680

GROMMET

12

ND116730-0490

DOOR ASS'Y

13

ND116730-0500

DOOR ASS'Y

14

ND245420-6002

CASE ASS'Y

15

ND116454-1780

CASE

16

ND949001-1730

SCREW

17

ND116420-2670

CORE ASS'Y

18

ND116127-5260

PIPE

19

195-979-4841

HOSE, 50MM

20

ND113600-9300

VALVE ASS'Y

21

ND017265-5480

HOSE

22

ND116127-5250

PIPE

23

ND017231-0690

CLAMP

24

ND246780-4000

CLAMP

25

ND949001-2690

SCREW

26

ND017732-3041

LEVER

27

ND91370-03081

SCREW

28

ND017732-3060

LEVER

29

ND017732-4600

LEVER

30

17M-911-3330

BUSHING

31

17M-911-3290

CLAMP

32

ND116662-3780

SHAFT

33

ND063700-6390

SERVO MOTOR ASS'Y

34

195-Z11-6280

BUSHING

35

ND90930-05201

SCREW

36

ND146668-4880

PACKING

37

ND056800-3130

RELAY ASS'Y

38

ND017660-3490

BRACKET

39

ND146525-3991

BRACKET

40

ND90930-05121

SCREW

41

ND146525-4000

BRACKET

42

ND90930-06141

SCREW

43

ND949351-0860

CLIP

44

ND443440-0030

SWITCH

45

ND949142-0160

O-RING

46

ND146668-2030

PACKING

47

ND146691-2790

CLAMP

48

ND91050-05081

SCREW
